Especificaciones
Las especificaciones pueden variar según talla, disponibilidad de componentes o cambios del fabricante sin previo aviso.
| Cuadro | M5 Alloy chassis and rear-end, Trail Geometry, horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 170mm of travel |
|---|---|
| Abrazadera del sillín | Alloy, 38.6mm |
| Horquilla | FOX FLOAT 38 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, 170mm of travel |
| Amortiguador trasero | FOX DHX Performance, Ride Dynamics Trail Tune, S1:230x60mm, S2-S5:230x62.5mm, S1: 350lbs,S2: 400lbs, S3: 450lbs, S4: 500lbs, S5: 550lbs, S6: 600lbs |
| Freno delantero | TRP Trail EVO, 4-piston caliper, hydraulic disc, 203mm |
| Freno trasero | TRP Trail EVO, 4-piston caliper, hydraulic disc, 203mm |
| Cambio trasero | Shimano Deore, M6100, 12pd, Shadow Plus |
| Mandos | Shimano Deore, M6100, I-Spec EV, 12 speed |
| Cassette | Shimano Deore M6100, 12-speed w/ Hyperglide+, 10-51t |
| Cadena | Shimano Deore M6100, 12spd |
| Platos y bielas | Shimano Deore, M6120, 32T ring, 55mm chainline, S1-4:165mm, S5: 170mm |
| Llantas | Specialized, hookless alloy, 30mm inner width, tubeless ready |
| Buje delantero | Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 32h |
| Buje trasero | Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h |
| Radios | DT Swiss Industry |
| Neumático delantero | Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" |
| Neumático trasero | Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3" |
| Cámaras | Standard, Presta valve |
| Manillar | Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, S1: 780mm width, S2-S5: 800mm width |
| Potencia | Alloy Trail Stem, 35mm bar bore |
| Puños | Deity Knuckleduster |
| Sillín | Bridge Comp, Hollow Cr-mo rails, 143mm |
| Tija del sillín | X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S3-S4: 170mm, S5: 190mm |
| Peso | 17.28 kg (38 lb, 1.5 oz) |
