Las especificaciones pueden variar según talla, disponibilidad de componentes o cambios del fabricante sin previo aviso.
| Cuadro y suspensión |
|---|
| Cuadro | New MY27 Carbon Advanced Composite Super Light Frame, Full Internal Cable Routing, Flat mount disc 12x142 |
|---|
| Horquilla | New MY27 Carbon Advanced Composite fork, Full Internal Cable Routing, Flat mount disc 12x100 |
|---|
| Transmisión |
|---|
| Cambio trasero | Shimano 105 Di2 R7150, Shadow 12-Speed |
|---|
| Mandos | Shimano 105 Di2 R7150, 2x12-Speed |
|---|
| Velocidades | 24 |
|---|
| Bielas y platos | Shimano 105 R7100 Chainring 52-36T 2x12-Speed, Crankset / XS size 165 mm / S, M size 170 mm / L size 172,5 mm / XL size 175 mm |
|---|
| Cassette | Shimano 105 R7101, 11-34T |
|---|
| Frenos |
|---|
| Frenos | Shimano 105 Di2 R7170, Hydraulic disc SM-RT70 160 mm / 140 mm |
|---|
| Ruedas |
|---|
| Juego de ruedas | Zipp 404 S, 50mm Tubeless ready Carbon rim |
|---|
| Neumáticos | Pirelli P Zero Race TLR Classic 622 x 30 Tan Sidewall |
|---|
| Cockpit |
|---|
| Manillar | New Velora Carbon Full Integratted Internal Cable Routing / XS size 80 x 360 mm / S size 90 x 380 mm / M size 100 x 380 mm / L size 110 x 400 mm / XL size 120 x 400 mm |
|---|
| Sillín | Selle San Marco Shortfit Open-fit 2.0 |
|---|
| Tija | New MY27 Aerodinamic Advanced Carbon Seat Post / XS, S size 315 mm / M, L, XL size 365 mm |
|---|
Geometría
| mm / grados | XS | S | M | L | XL |
|---|
| Stack | 503 | 518 | 538 | 557 | 581 |
|---|
| Reach | 373 | 378 | 383 | 392 | 402 |
|---|
| Tubo sillín | 460 | 480 | 500 | 520 | 540 |
|---|
| Ángulo sillín | 74.5 | 74.5 | 74 | 74 | 74 |
|---|
| Tubo superior | 512 | 521 | 537 | 552 | 568 |
|---|
| Tubo dirección | 95 | 111 | 128 | 148 | 173 |
|---|
| Ángulo dirección | 71.5 | 71.5 | 72.5 | 72.5 | 72.5 |
|---|
| Vainas | 410 | 410 | 410 | 410 | 410 |
|---|
| Distancia entre ejes | 972 | 985 | 982 | 997 | 1014 |
|---|
| Caída pedalier | 77 | 77 | 75 | 75 | 75 |
|---|
| Longitud potencia | 80 | 90 | 100 | 110 | 120 |
|---|
| Ángulo potencia | 10 | 10 | 10 | 10 | 10 |
|---|
| Ancho manillar | 360 | 380 | 380 | 400 | 400 |
|---|
