Las especificaciones pueden variar según talla, disponibilidad de componentes o cambios del fabricante sin previo aviso.
| Motor y batería |
|---|
| Motor | Avinox M2S, 130Nm, 1500W |
|---|
| Batería | Avinox 800 Wh |
|---|
| Capacidad de batería (Wh) | 800 |
|---|
| Display | Avinox DP100 |
|---|
| Cargador | Avinox 12A |
|---|
| Cuadro y suspensión |
|---|
| Cuadro | Reason Full Carbon Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel: 160 mm |
|---|
| Horquilla | Fox 38 Float Factory E-Bike Optimized, 160mm Travel, Grip X2 |
|---|
| Recorrido horquilla (mm) | 160 |
|---|
| Amortiguador | Fox Float X Factory, 210 x 55 mm |
|---|
| Transmisión |
|---|
| Cambio trasero | Sram S1000 EAGLE AXS T-TYPE, 12-Speed |
|---|
| Mandos | Sram AXS Pod |
|---|
| Velocidades | 12 |
|---|
| Bielas y platos | Sram EAGLE T-TYPE Avinox Chainring 36T 12-Speed, Crankset 165mm |
|---|
| Cassette | Sram XS 1270 T-TYPE, 10-52T |
|---|
| Frenos |
|---|
| Frenos | Shimano XT M8220, Hydraulic Disc 4-Piston, RT-CL800 203 mm |
|---|
| Ruedas |
|---|
| Juego de ruedas | DT Swiss H 1900 SPLINE, 30mm Tubeless ready Aluminium rim, 15x110/12x148 mm |
|---|
| Neumáticos | Maxxis Assegai 29x2.5 DD 3C MaxxTerra / Maxxins Minion DHR II 29x2.4 DD 3C MaxxTerra |
|---|
| Cockpit |
|---|
| Manillar | Race Face Era, 35 x 800 x 20 mm |
|---|
| Potencia | Satori New Ursa,35 x 35 mm |
|---|
| Sillín | Fizik Terra Aidon X5, 145 mm |
|---|
| Tija | Fox Transfer Factory Ø31.6 mm S size 150 mm Drop / M size 180 mm Drop / L and XL size 210 mm Drop |
|---|
Geometría
| mm / grados | S | M | L | XL |
|---|
| Stack | 617 | 635 | 653 | 664 |
|---|
| Reach | 442 | 470 | 500 | 512 |
|---|
| Tubo sillín | 400 | 420 | 455 | 460 |
|---|
| Ángulo sillín | 77 | 77 | 77 | 77 |
|---|
| Tubo superior | 584 | 617 | 651 | 665 |
|---|
| Tubo dirección | 100 | 120 | 140 | 152 |
|---|
| Ángulo dirección | 63.5 | 63.5 | 63.5 | 63.5 |
|---|
| Vainas | 450 | 454 | 458 | 458 |
|---|
| Distancia entre ejes | 1233 | 1274 | 1317 | 1334 |
|---|
| Caída pedalier | 30 | 30 | 30 | 30 |
|---|
| Altura pedalier | 348 | 348 | 348 | 348 |
|---|
